Domino F520i User Manual

TECHNICAL REFERENCE
4-6 EPT031055 Issue 2 September 2017
CONTROLLER
POWER
Controller Type F-Series
Electrical Requirements:
Mains Power:
Voltage 100-240VAC
Frequency 50Hz / 60Hz
IP 55 Enclosure:
Dimensions
(L x W x H) [mm]
405x560x430
Cooling fan cooled
Operating Temperature
5° to 35° C
(41° to 95°F)
Environment Humidity
max. 90% RH,
non condensing
IP 55 Enclosure with 45°C Option
Dimensions
(L x W x H) [mm]
405x680x430
Cooling water cooled
Operating Temperature
5° to 45° C
(41° to 113°F)
Environment Humidity
max. 90% RH,
non condensing
Output
Power Output via the X2,X3,X4, X6,X7
X28 connectors (together)
30 Watts
Power Consumption Complete
System
Idle Mode 70 VA
Printing Mode 420 VA
