Add an Image
To insert an image into the message:
(1) Press on the screen within a specific area of the Message Editor where you require
the item to appear. A cross hair will appear at this location.
(2) Select the Image icon from the Add menu.
(3) An images folder stored in the printer will open.
(4) Browse for the required image.
(5) Select the green tick icon to insert the image.
Note: Monochrome Bitmap (*.bmp), DXF (*.dxf) (up to Version 12, information about 3-
dimensional objects is discarded, fonts and labels are not supported) and Hewlett
Packard Graphics Language HPGL (*.plt) black white graphic file formats are
supported.
Supported commands for HPGL import are: Arc Absolute, Arc Relative, Plot
Absolute, Plot Relative, Pen Up, Pen Down
(6) Select the Move icon to move the copied item to the desired location within the
message.
(7) Activate the message for printing by sending it to the printer via the File menu .
(8) Use the File Manager (Home > Settings > File Manager) to copy an image from a
USB device to the controller.
