16
ENGLISH
SETTINGS
Warning: It is necessary to get off the bike to proceed to the settings (saddle, handlebar)
The warning decals shown on this page have been placed on the product in the locations shown below. If a decal is missing or
illegible, please contact your nearest DECATHLON store and order a free replacement decal. Place the decal on the product in
the location shown.
HOW TO ADJUST THE
POSITION OF THE SEAT
For effective exercising, the seat
should be at the proper height.
As you pedal, there should be a
slight bend of the knees when the
pedals are at the lowest position.
To adjust the seat, first hold the
seat (45) and loosen the seat post
knob (41). Align one of the holes
in the seat post (4) with the hole in
the frame tube (4). Insert the seat
knob into the frame and the seat
post, and tighten the seat knob
into the frame.
CAUTION :
• Be sure to insert the seat post
knob through one of the holes
in the seat post, and firmly tigh-
ten the seat post knob.
• Never exceed the maximum
saddle height.
HOW TO ADJUST THE
HANDLEBAR
To adjust the handlebar (48), loo-
sen the handlebar knob (51).
When the handlebar is in the sui-
table position, tighten the knob
(51).
HOW TO ADJUST THE
PEDAL STRAP
To adjust the pedal strap, first
release the brake system under the
pedal. Adjust the strap to the desi-
red position and then press the
brake to block the strap.
HOW TO LEVEL THE BIKE
If the bike rocks during use, turn
one or both plastic caps (8) at the
end of the back foot (3) until the
rocking stops.
SETTING THE RESIST
ANCE
The brakes system and the resis-
tance are coupled with the peda-
ling speed.
The resistance setting is done with
the knob indexed (46) from 1 to
8.
Position 1 corresponds to the least
resistance and position 8 to the
highest resistance.
You can adjust the resistance
while pedaling.
Product in accordance with
EN 957 class HC, ASTM F 1250 class B, GB17498,
not suitable for therapeutic purposes.
DECATHLON - 4, bvd. de Mons – BP299
59665 Villeneuve d’Ascq Cedex – France
F : (+).33.3.20.33.50.00
-----------------------------------------------------------
EN957 Class HC, ASTM F1250 class B, GB17498
Item n°: x/xxx.xxx Order n°: xxxxxxxxxx
Supplier code: xxxxxx Made in China
WARNING
• Misuse of this product may result in
serious injury.
• Read user’s manual and follow all
warnings and operating instruc-
tions prior to use.
• Do not allow children on or around
machine.
• Replace label if damaged, illegible,
or removed.
• Keep hands, feet and hairs away
from moving parts.
MAXI
100 kg / 220 lbs
1 3
4
5
2
