CONNECTING CALL BUTTONS TO THE MULTI TENANT MODULE
Applies only to devices with
2 and more illuminated call
buttons with nameplate.
Connect only call buttons to the
Multi Tenant Module (e.g. Multi
Tenant Module MTM18A) certified by
Bird Home Automation.
J18
J1
= 1. call button jack
= 18. call button jack
