2.1 Re-Programming the Master Code
2.2 Relay Strike Time
Step 1. Open the cabinet and locate the
Master Code switch on the circuit board.
Turn switch ON.
Step 2. Enter a four-digit master code using the keypad, then press “
*
” (A short beep will be heard).
Step 3.
Turn OFF the Master Code switch and close cabinet.
Write down master code and keep it in a secure place.
? ? ? ?
any four numbers
Then press
“BEEP”
Same keystrokes as written in this manual: [ _ _ _ _
*
(beep)]
Actual keystrokes used on keypad:
SECTION 2 - PROGRAMMING
Before You Start Programming: IMPORTANT! Make sure the 1504/1506 has power and we suggest that you become familiar
with programming instructions before beginning any programming.
Keep a record of the programmed codes by completing the tables on pages 24 and 25.
The Master Code has been pre-programmed at the factory to 9999. This programming sequence re-programs the MASTER
CODE if desired. The master code is the four-digit number required to gain access to the system memory. You MUST know the
master code before programming ANY features.
Important Note: After re-programming the master code, write it down and keep it in a safe place. There is no way of retrieving
the master code after it has been programmed in. If you forget it, you will have to program in a new one but all other previously
programmed information will remain intact.
The relay strike time sets the amount of time that the relay(s) will be activated when a valid entry code is entered on the keypad.
The unit has two relays, both of which can be programmed with individual strike times. Setting the strike time to “00” will
activate the relay for ½ second. It can be set to a max of 99 seconds. Two digits MUST be entered in the fields.
Factory setting is 01 (1 Second).
1. Press
*
0 3 and enter the MASTER CODE. [
*
0 3 _ _ _ _ (beep)]
2. Enter the two-digit strike time for Relay 1 (00-99), then press
*
. [ _ _
*
(beep)]
3. Enter the two-digit strike time for Relay 2 (00-99), then press
*
. [ _ _
*
(beep)]
4. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
2.3 X Strikes for Invalid Entry Code Attempts
This keypad has a 3-minute lockout feature that is activated when “X” number of INVALID entry codes are entered on the
keypad. The “X” strikes can be programmed from 1 to 9 invalid attempts before the lockout feature is activated.
Factory setting is 3 (3 Attempts).
1. Press
*
0 4 and enter the MASTER CODE. [
*
0 4 _ _ _ _ (beep)]
2. Enter the single-digit invalid attempts before the lockout feature is activated (1-9), then press
*
. [ _
*
(beep)]
3. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
ON
OFF
ON
OFF
Note: After you turn ON the master code switch, the system will sound a short
tone after 30 seconds if the master code is not entered. This tone will continue
every 30 seconds until a new master code is entered, or until the switch is
turned off.
