DoorKing 1504-096 Installation And Owner's Manual

1506-065-K-6-17
7
These wire diagrams are provided for convenience only. For detailed wiring information on Aiphone products, visit their website
at www.aiphone.com.
1.5 1504 Aiphone Intercom Station Connections
Intercom Station
1504
AIPhone LEM Series
2-Wire System
3-Wire System
E
1
Push to Call Button
Speaker
Blue Blue
Red
Red
Capacitor
47uF
+
1504
Push to Call Button
Speaker
Blue Blue
Red
Red
Capacitor
47uF
+
Intercom Station
Hands-Free Selective Call Systems
These series of systems are purchased separately.
AIPhone LEF Series
E
1
–
