DoorKing 1504-096 Installation And Owner's Manual

1506-065-K-6-17
12
2.12 Hold Boundary Programming
1. Press
*
0 7 and enter the MASTER CODE. [
*
0 7 _ _ _ _ (beep)]
2. Choose and enter a four-digit code for the LOWER hold boundary, then press
*
. [ _ _ _ _
*
(beep)]
3. Choose and enter a four-digit code for the UPPER hold boundary, then press
*
. [ _ _ _ _
*
(beep)]
4. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
The entry system hold boundaries establish a set of four-digit entry codes that will latch Relay 1 ON, Relay 2 ON, or BOTH
Relay 1 and Relay 2 ON (depending on the divide number programmed and the hold boundaries that have been programmed)
indefinitely. To un-latch the relay(s), a four-digit entry code within the hold boundary is entered on the keypad.
Factory setting is NO hold boundary programmed (# # # #).
Note: Hold boundaries can only be established for the four-digit entry codes. Five-digit entry codes have no hold boundaries.
Note: To delete existing hold boundaries, enter # # # # in steps 2 and 3.
Note: See section 3.5 for examples.
Note: See section 3.6 for examples.
Note: See section 3.6 for examples.
2.13 Time ZONE 1 Boundary Programming
Programming the LOWER and UPPER boundaries for time ZONE 1 establishes a set of four-digit entry codes that will be denied
access if the time zone 1 input (terminal 4) is activated. Note: This time zone does not affect the five-digit entry codes.
Factory setting is NO zone 1 boundary programmed (# # # #).
1. Press
*
0 5 and enter the MASTER CODE. [
*
0 5 _ _ _ _ (beep)]
2. Choose and enter a four-digit code for the LOWER boundary, then press
*
. [ _ _ _ _
*
(beep)]
3. Choose and enter a four-digit code for the UPPER boundary, then press
*
. [ _ _ _ _
*
(beep)]
4. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
Note: To delete existing time zone 1 boundaries, enter # # # # in steps 2 and 3.
2.14 Time ZONE 2 Boundary Programming
Programming the LOWER and UPPER boundaries for time ZONE 2 establishes a set of four-digit entry codes that will be denied
access if the time zone 2 input (terminal 3) is activated. Note: This time zone does not affect the five-digit entry codes.
Factory setting is NO zone 2 boundary programmed (# # # #).
1. Press
*
0 6 and enter the MASTER CODE. [
*
0 6 _ _ _ _ (beep)]
2. Choose and enter a four-digit code for the LOWER boundary, then press
*
. [ _ _ _ _
*
(beep)]
3. Choose and enter a four-digit code for the UPPER boundary, then press
*
. [ _ _ _ _
*
(beep)]
4. Press 0 # TOGETHER to end. [0 # (beeeeeep)]
Note: To delete existing time zone 2 boundaries, enter # # # # in steps 2 and 3.
