37
1838-065 Issued 3-19
Version D
3.7 Programming Four-Digit Entry Codes
A DoorKing remote keypad (P/N 1814-075) is required if four-digit entry codes are going to be used to access a door or gate.
DO NOT confuse a FOUR-digit ENTRY code with a FIVE-digit PIN (Personal Identification Number) device code that is entered
on a remote wiegand keypad (see previous page). Four-digit entry codes can ONLY activate relays 0, 1 or 2 on the 1838 circuit
board. They will NOT work on wiegand devices connected to tracker expansion boards. If tracker expansion boards are
controlled by relay 2, the four-digit entry codes must ONLY be set to activate relay 0 or 1. If relays 1 and 2 are used to control
tracker expansion boards, then four-digit entry codes must ONLY be set to activate relay 0.
Each entry code that you enter must be assigned to a directory code that you select (that was programmed in section 3.5.2).
Only ONE entry code can be programmed for each directory code. You cannot duplicate entry codes.
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the entry code will be assigned to (1, 2, 3 or 4 digits, section
3.5.1), then press (beep).
3. Choose and enter a four-digit entry code, press (beep).
4. Repeat steps 2 and 3 to enter additional entry codes. (You cannot duplicate entry codes)
5. Press together to end this programming sequence (beeeeeep).
? ? ? ?
2
0
0
3.7.1 Programming Four-Digit Entry Codes
Four-digit entry codes can be made to activate relay 0, relay 1, or relay 2 or any combination of relays by programming HI and
LOW ranges for each relay. Ranges between relays may overlap, which will cause more than one relay to activate if this is
desired. For example, if the low boundary for relay-0 and relay 1 is 2000, and the hi boundary is 3000 for relay 0 and 4000 for
relay 1, then entry codes between 2000 and 3000 will activate both relays, and entry codes between 3001 and 4000 will only
activate relay 1.
3.7.3 Entry Code Ranges
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) to set relay 0, or (beep) to set relay 1, or (beep) to set relay 2 boundary.
3. Enter the four-digit LOW boundary, then press (beep).
4. Enter the four-digit HI boundary, then press (beep).
5. Repeat steps 2, 3, and 4 to set the other relay boundaries.
6. Press together to end this programming sequence (beeeeeep).
? ? ? ?
2
1
0
0 1 2
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the desired entry code has been assigned to (1, 2, 3 or 4 digits,
section 3.5.1), then press (beep).
3. Enter , then press (beep).
4. Repeat steps 2 and 3 to delete additional desired entry codes.
5. Press together to end this programming sequence (beeeeeep).
? ? ? ?
2
0
0
3.7.2 Delete Entry Codes
