DoorKing 2112 User Manual

2112-065-G-12-21
12
2112 Wiring Schematic
Microphone
8863-502
Video
1894-041
LED Push Button
Speaker
Purple
Orange
Gray
White
White
Yellow
White
White
Red
Red
Green
5V OUT GND CALL LED GND TALK LED GND
TB2
TB3
CARD 1
B
CARD 1
A
GND
+12VDC
OUT
GND
+ VDC
OUT
GND
RELAY 1
COM
RELAY 1
NC
RELAY 1
NO
POT 1
TB2 TB3 TB1
TB4
J1
2
1
4
3
J3 J8
+
POT 2
MIC OUT 1
BATTERY
POWER
MAIN
POWER
KEYPAD
TB4
GND
BUTTON
Z
GND
TAMPER
SW
GND
BUTTON
A
GND
BUTTON
CALL
GND
POST
KEY SW
TB1
BATT +
GND
RELAY 3
COM
RELAY 3 RELAY 2
COM
RELAY 2
NC
RELAY 2
NO
N/C
16 VAC
IN
16 VAC
IN
SOUND CARD
8168-102 POWER
MUTE/REC
DISPLAY
HDMI
A/V
PWR IN
CAMERA
ETHERNET
USB
USB
Lighted Keypad
J3 11-Pin Door
Accessories Plug
J3 11-Pin Door Accessories Plug
Red
Wire
Right
Optional Cellular Module
Optional Cat5 Connection
Cat5
HDMI
USB
x2
USB
x2
Raspberry Pi 3 Model B
Blue end MUST be inserted
on LEFT side of video
connector as shown.
Lift Up Tabs to
Remove
Video Ribb
o
n
Video Connecto
r
Tab
Tab
Video
Ribbon
111
1 Gray 2 Orange 3 Purple 4 White 5 Red 6 White 7 White 8 Yellow 9 Green 10 White 11 Red
Keypad
Speaker
Push Button
Microphone
