SPECIFICATIONS
11” 6.25”
6.75”
2”
875” Dia
2.5”
2.5”
1.125” Dia
5.5”
3”
3.75”3.125”
Bottom View
Side View Back ViewFront View
0
0
4
4
5
5
6
6
1
1
2
2
3
3
7
7
8
8
9
9
Surface Mount Dimensions
R
ough-In
Box
Flush Mount Dimensions
7.5”
6.25” 7.25”
9.25”
5”
3.5”
3.5”
10.25”
10”
12”
4.5”
4.25”
2.625”
.875” Dia
5” 2.5”
1.25” Dia
Rough-In Box
Rough-In Box
Rough-In BoxFlush Box
Flush Box
Bolt holes (4) to secure flush box
inside rough-in box.
Flush Box
Flush Box
Flush
Box
Side Views
Bottom Views
