MicroController Control System Systems Operation
The percent “on-time” of the voltage at gate of TA is
also the percent "on-time" of the MOSFET TA.
As the “on-time” increases, the average voltage
applied to the drive motor increases which
increases the speed of the lift truck. The percent
“on-time” out of the logics is determined by how far
the accelerator is depressed.
