Doosan B20S-3 - MOSFET Connections; MOSFET Measurements

6
MicroController Control System Specifications
MOSFET Connections
1. Gate 2. Drain 3. Source
2
2
123
3
1
MOSFET Measurements
SPECIFICATIONS
Multimeter Setting (+) Test Lead (-) Test Lead Results
Resistance Gate Source Over 20 Mohms
Resistance Gate Drain Over 20 Mohms
Resistance Drain Source Over 20 Mohms
Resistance Drain Gate Over 20 Mohms
Resistance Source Gate Over 20 Mohms
Resistance Source Drain Over 20 Mohms
Diode Drain Source 0.4 ~ 0.7V
