MicroController Control System Testing And Adjusting
Quick Diagnostics Mode
This will enable Quick Diagnostics of some of the
components without console and access to
controller room.
Procedure
1.
Initial set
- Seat switch : Open
- Directional switch : Forward
- Handbrake : Released
- Accelerator : Depressed to above half position.
2.
Key switch to on
display ‘A3’ and accelerator symbols
3.
Directional lever to neutral and release the
accelerator
display ‘A0’ only
4.
Some switch to on display as following codes.
and switches to off display ‘A0’
SWITCH DISPLAY
ALL OFF A0
REVERSE A2
FORWARD A3
LIFT 1 TO 10
TILT A6
AUX 1 A7
AUX 2 A8
HAND BRAKE A9
ACCELERATOR SYMBOLS
