Power Train Disassembly & Assembly44
Item Description Q’ty Item Description Q’ty Item Description Q’ty
1 Brake Drum 1
2Mangetic Fill/Dran Plug 1
3Planetary Assembly Cover 1
4 Capscrew 6
5 Hardened Washer 6
6 Thrust Button 1
7 Dowel 3
8Planetary Spider Assembly 1
9 Machine Screw 5
10 Planetary Pinion Shaft 3
11 Planetary Pinion 3
12 Thrust Washer 3
13 Snap Ring 1
14 Planetary Sun Gear 1
15 Thrust Washer 1
16 Wheel Bearing Nut 1
17 Planetary Ring Gear 1
18 Capscrew 2
19 Lock 1
20 Planetary Ring Gear Hub 1
21 Outer Bearing Cone 1
22 Outer Bearing Cup 1
23 O-Ring 1
24 Hub and Cup Assembly 1
25 Wheel Nut 10
26 Wheel Stud 10
27 lnner Bearing Cup 1
28 Inner Bearing Cone 1
29 Oil Seal Assembly 1
30 Spindle Assembly 1
31 Capscrew 13
32 Hardened Washer 13
33
Axle Shaft (Left-Hand, Right-Hand)
2
Axle for D150&160S-5 Truck
