Doosan D120 - Specifications; Axle Torque Specifications

Power Train Specifications5
Specifications
Axle for D100/120 & D110/130S-5 Truck-Wheel End Torque Chart
Item Fastener Torque Value
1 Wheel rim nut 500 lb•ft (680 N•m)
2pinion shaft set screw 35 lb•ft (47 N•m)
3 Oil fill/level/drain plug 35 lb•ft (47 N•m)
4 planetary spider-to-wheel hub slotted head screw Hand tighten(no specification)
5 Spindle and brake spider mounting 310-400 lb•ft (420-542 N•m)
6 Camshaft bracket clamp 35-50 lb•ft (47-68 N•m)
7 Camshaft bracket to spider 85-115 lb•ft (115-156 N•m)
8 Wheel bearing adjusting nut Refer to instructions on page 50
