Power Train Disassembly & Assembly
Axle for D150 & D160S-5
Truck
Removal and Disassembly -
Planetary Axle
NOTE : Numbers in parenthesis ( ) refer to the Axle
for D150 Truck exploded view on page 44.
To prevent serious eye injury, always wear safe
eye protection when you perform vehicle
maintenance or service.
Remove the Brake Drum
Block the wheels to prevent the vehicle from
moving. Support the vehicle with safety stands.
Do not work under a vehicle that is supported only
by jacks. Jacks can slip or fall over. Serious
personal injury can result.
1. Make sure the vehicle is on a level surface.
2. Place blocks under the wheels not being serviced
to keep the vehicle from moving.
3. Raise the vehicle so that the wheels of the axle to
be serviced are off the ground. Support the vehicle
with safety stands.
