Doosan DX220A - LIFTING WITH SLING

OP001763
5-5
Transportation
LIFTING WITH SLING
1. Refer to “Specification” on page 7-1 of this manual for
information on weight and dimensions.
2. Use properly rated cables and slings for lifting.
3. Position machine for a level lift.
4. Lifting cables should have a long enough length to prevent
contact with the machine. Spreader bars may be required.
NOTE: If spreader bars are used, be sure that cables
are properly secured to them and that the angle
of the cables is factored into the lift strength.
2
2
3
3
2 2
3
3
FG014870
Figure 11
FG016361
Figure 12
WARNING
Improper lifting can allow load to shift and cause injury or
damage.
