Doosan DX220A - INSTRUMENT PANEL

OP001760
2-19
Operating Controls
INSTRUMENT PANEL
C
H
E
F
H
C
POWER
1
5
2
3
6
7
AUTO
4
ESC
8
FG014202
E/G SPEED
02/05 [MO] 11:30
1700
RPM
CHECK
789101112
5
1
2
14
13
3
4
16
18
19
15
17
6
Figure 35
Reference
Number
Description
1 Fuel Gauge
2
Engine Coolant Temperature
Gauge
3 Hydraulic Oil Temperature Gauge
4
Multifunction Gauge and Graphic
Information Area (See page 2-25)
5 Digital Clock
6 Hour Meter
7 Charge Warning Light
8 Engine Oil Pressure Warning Light
9
Engine Coolant Temperature
Warning Light
10 Engine Check Warning Light
11 Preheat Indicator Light
12 Work Light Indicator Light
13
Power Mode Selector Button
(See page 2-30)
14
Auto Idle Selector Button
(See page 2-30)
15
Flow Control Button
(See page 2-31)
16
Up Arrow Button
(See page 2-32)
17
Down Arrow Button
(See page 2-33)
18
Display Selector Button
(See page 2-33)
19
Selection Button
(See page 2-33)
Reference
Number
Description
