- 168 -
LP Engine G430(3.0L) Base Engine Service Procedure
Camshaft Installation
IMPORTANT: If camshaft replacement is required, the
valve lifters must also be replaced.
1. Carefully rotate and install the camshaft into the
engine.
2. Install the two camshaft retainer bolts working
through the holes in the camshaft sprocket. Be sure
to align the camshaft and the crankshaft sprocket
alignment marks.
Tighten
Tighten the camshaft retainer bolts to 9 N•m (80 lb•in).
Engine Front Cover and Oil
Seal Installation
Tools Required
• J 35468 Engine Front Cover Aligner and Oil Seal
Installer
1. Use the J 35468 in order to install the engine front
cover oil seal.
VE109-3L
VE108-3L
