HM 5000/6300/8000 HM4digitATCE26

10) From the PMC DATA screen, check the tool number (D450) in the spindle as well as the tool

number (D452) in the waiting pot, and make correction if necessary. When each axis returns to

their respective home position, ATC troubleshooting is completed.

D450 : Tool number in the spindle

D452 : Tool number in the waiting pot

Table of Contents

(1) If the changer arm is stuck while trying to pull out a tool from the spindle (in the state of Tool Unclamp)3
In most cases, this happens when the changer arm is stuck in the spindle while trying to pull out a tool after Utool unclamping is performedU, causing to trigger the " 2062 M06 Command Over Time” alarm.3
(2) If the changer arm is stuck in the spindle after changing a tool (in the state of Tool Clamp)3
In most cases, this happens when the changer arm gripper is stuck in a tool after Uthe changer arm changed the tool and performed the tool clampingU, causing to trigger the " 2062 M06 Command Overtime” alarm.3
(3) If the changer arm has stopped operation irrelevantly to the spindle3
This happens if the machine is emergency stopped or there occurs a power failure while performing the tool changing.3
▶ ATC Recovery3
