Doosan Vision DVSD-TT Series User Manual

DOOSAN SERVO

2
1000 2000 30000
60
(6)
120
(12)
180
(18)
240
(24)
Torque [kg.cm (Nm)]
Speed [rpm]
Continuous Duty Zone
Intermittent Duty Zone
1.2 Specifications for Servo Motor
Items
Specifications
SERVO
MOTOR
Rated output
kWatt
0.8
1.5
2.0
4.0
Rated torque
kgcm
25.98
73.08
97.44
194.88
Nm
2.55
7.16
9.54
19.11
Continuous
maximum
torque
kgcm
77.95
219.24
292.32
584.64
Nm
7.64
21.49
28.66
57.32
Rated speed
RPM
2000
Maximum
speed
RPM
3000
Power rate
kW/S
23.64
13.28
42.29
34.78
Rotor Inertia
×10 ￣⁴ kg· ㎡
2.8
39.4
22
107
Insulatioin
F Class
Detector
Multi-turn Absolute Encoder
(17bits/1rotation, rotation rate :16bits)
Protection, Cooling method
Totally closed, self cooled
Ambient temperature
0～ 40°C
Ambient humidity
20～ 80 %
Mounting structure
Flange type
Insulation resistance
DC 500V 20 Mohm
Insulation grade
AC 1500V 1분간
Vibration
V15
1.3 Torque-Speed Characteristics of Servo Motor(2.0KW)
※ Refer to Motor Specifications for details
