Dormakaba ED100 Operating & Maintenance Manual

5
SWING DOOR LOG BOOK
2017-11
Report for initial inspection
To be completed by a qualiied technician at installation
The following list of components and functions to be inspected is only a reference and shall help the inspector
during inspection. From case to case, the inspection can be more or less comprehensive. In principle, the inspector
has to perform a visual inspection and functional tests to check the system for completeness. In addition, the
system status and the eficiency of the components and the respective safety equipment require inspection.
Please consider the separate inspection instructions supplied with the individual door types.
. General
• Functionality of door system
• Proper mounting
• Connections/Power supply
• Guide rails and base sections
• Force transmission/Incremental encoder
• Bearings
• Glazing, Cover
• Coating, Corrosion protection
• All documentation complete
. Check safety equipment according
to risk assessment to EN 
• Finger protection (crushing, shearing
and drawing in)
• Safety sensors/Sensor monitoring
• Reversing/Stop equipment
• Safety screen
• Safety contact strips (SCS)
• Force limitation
• Emergency pushbuttons
• Safety sensors
• Fire alarm connection
• Batteries
. Control elements
• Pushbuttons/switches
• Contact mats
• Radio controls/Remote controls
• Card readers
• Motion detectors
. Function
• Friction clutch
• contact (limit switch)
• NO contact (limit switch)
• Locking device, Deactivation
• Deactivation of safety equipment
• Emergency manual operation
• Emergency Opening/Rubber cord/
Auxiliary drive
. Check door system for proper
functioning in all operation modes
• OFF
• AUTOMATIC
• PERMANENT OPEN
• PARTIAL OPEN
• EXIT ONLY
• LOCKING DEVICES
Date of inspection:. .........................................................................................................................
Name of inspector (in block letters): .........................................................................................................................
(Qualiied technician)
Note: The safety compliance of an automatic door system is dependent on the appropriate choice and
combination of other safety equipment with the operator and must be assessed as the whole system.

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
