dormakaba ED50/ED100/ED250 OHC Header
Setup and Troubleshooting Instructions
Chapter 3
 ED//ED OHC door configurations
. OHC single door configurations
Fig. 3.1.1 LH inswing RH inswing
Fig. 3.1.2 LH outswing RH outswing
Fig. 3.2.4 RH double egress
Fig. 3.2.3 Inswing
Fig. 3.2.1 Outswing
Fig. 3.2.2 LH double egress
. OHC pair door and double egress door configurations
Jambs and doors supplied and installed by customer.
Locks optional.

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
