dormakaba ED900 Setup and Troubleshooting Instructions Chapter 2
. Safety instructions.
This document contains important instructions for
setup and troubleshooting instructions for ED fine
cover swing door operators.
Review these instructions thoroughly prior to setup, and
follow them carefully during installation, setup,
troubleshooting and maintenance.
. Door signage requirements.
Proper signs and labels shall be applied and maintained on
the door controlled by an ED fine cover swing door
operator.
• Reference ED Installation Instructions.
. Safety warnings.
WARNING
An incorrect installation may result in damage to
equipment or incorrect equipment operation.
WARNING
Hazard to mechanical processes by use of
control settings, elements, or procedures not
documented in this manual!
WARNING
Electric shock hazard!
By use of control elements, settings, or
procedures not documented in this manual!
WARNING
Work on electrical equipment and Vac
wiring installation must be only be performed
by qualified personnel!
WARNING
Metallic doors must be grounded per national
and local codes!
Safety information
WARNING
Hand pinch point and crushing hazards at door
closing edges!
WARNING
Crushing hazards at door closing edges!
. Residual hazards.
WARNING
After installation, hazards such as minor
crushing, impact with limited force, and risk to
unsupervised children may exist depending on
structural design of door area, type of door,
and any safeguards that have been
implemented.
WARNING
Hand pinch point and crushing hazards at arm
and track!
Fig. 2.1 Door closing edges
Fig. 2.3 Pull arm
Fig. 2.2 Push arm
Opposing
closing edge
Main
closing edge
Secondary
closing edge
