MAINTENANCE
POWER UNIT REFERENCE LIST - “T” TYPE
2-12
Part # Ref # Description Qty
03-5374 1 10 HP/3PH SUBMERSIBLE MOTOR FR56 1
02-4988 2 GEAR PUMP 10.5GPM 1
02-4993 3 3/4" STRAINER 1
02-0357 4 CONTROL VALVE VICKERS 1
02-4990 5 PRESSURE SWITCH, CD174 NASON 1000-3000PSI 1
02-0215 6 SIDE OIL LEVEL GAUGE SG-5-T-G 1
02-4991 7 ALL "O" RING DO2 SUBPLATE 1
02-2253 8 1" PIPE PLUG 1
99-7392 11 SUBMERSIBLE RESERVOIR 24"X13"X22", 20GAL 1
99-7391 13 BPS-40N12 3/4" BREATHER 1
03-4926 14 CONTROL PANEL 12"X18"X6" NEMA 4 1
02-4992 15 TEMP & OIL LEVEL SENSOR TL009 1
02-5086 20 RELIEF VALVE 1
06-3391 21 LEXAN DECAL - OPERATING INSTRUCTIONS 1
02-5006 22 TANK SEAL 1
Match the reference numbers to the drawing on the previous page. To order replace-
ment parts, please call our parts department at 1-800-633-8974 or log on to
www.parts1stop.com to order online.
