18
9.2 Hydro-Unit MC ++
ATTENTION
See factory settings 3-2-2-1
When as a result of a increasing water volume the
pressure drops below the pressure set point, a pump
will be switched on. When the required system
pressure has been reached, the pumps are switched
off one at a time. The minimum run time related
switch-off delay is optimized constantly, which results
in a considerable energy saving.
Table 17: Specific parameter settings MC ++
Figure 6: 1 pump operation
Figure 7: 2 pump operation
Figure 8: 3 pump operation
Parameter Value
3-3-1 Number of pumps 1
2
3
4
5
6
3-3-2 Inlet Switch
Pressure
Level / valve ON-OFF
Level / valve prop.
3-3-3 Discharge Fixed Speed
3-5-1 Set point .... kPa
3-5-3 Bandwidth 50
3-5-13 Low pressure alarm 100 kPa
3-6-1 Opt. pump starts/h 30
3-6-2 Min. run time 1 s
3-6-3 Min. run time cor. 1 s
3-6-8 Run-dry delay Default 30 s
Float/level control 1 s
