3-4-5-6-3 Power 3 0
1.5
100
es
3-4-5-6-4 Power 4 0
1.5
100
es
3-4-5-7 Motor settings e n Motor Paramters settings
3-4-5-7-1 Rated Motor Power 0
1.5
110
e s Motor rating plate
3-4-5-7-2 Rated Motor Speed 300
1425
3600
e s Motor rating plate
3-4-5-7-3 Rated Freq 45
50
e s Motor rating plate
3-4-5-7-4 Rated Current 0.1
10
999
e s Motor rating plate
3-4-5-7-5 Rated Cosphi 0.1
0.81
0.99
e s Motor rating plate
3-4-5-8 Pump parameters e n Pump Paramters settings
3-4-5-8-1 Rated Pump Speed 300
2900
36000
e s Pump rating speed
3-5 Pressure e n System pressure settings
3-5-1 Set point 0
400
1000
e c System pressure set point
3-5-3 Bandwidth 0
5
999
ecBandwidth
3-5-4 Accumulation press. 0
30
999
e c Membrane tank (water) pressure accumulation
prior to the system switch-off
3-5-5 Max.set point 400
1000
e s Upper limit for the setpoint value to be set by the
customer
3-5-9 Adapt. setpoint 0
400
1000
e c Alternative setpoint alternating by clock settings.
3-5-10 Delta p -999
0
999
e c Quadratic function to correct the setpoint when a
pump is switching on or off
3-5-11 High pressure alarm 400
1000
e c Upper limit value for the system pressure to shut
down or notification only (signal)
3-5-12 High pressure action e c Selection parameter to define the action at system
over-pressure (shut down or signal only)
3-5-12.1.1 #0-0 High pressure action shutdown pumps
only message
e c Selection parameter to define the action at system
over-pressure (shut down or signal only)
3-5-13 Low pressure alarm 0
400
e c Under limit value for the system pressure to shut
down or notification only (signal)
