10.1.5 Quick menu (Quick access button "OK")
Table 43: Parameter list Megacontrol version 1.7.1
4-3-1 HMI Serial Number e n
4-3-2 HMI FW-Version e n
4-3-3 HMI FW-Revision e n
4-3-4 HMI HW-Revision e n
4-4 Profibus Info e e
4-4-1 PB FW-Version e n
4-4-2 PB FW-Revision e n
4-4-3 PB HW-Revision e n
4-5 Modbus Info e e
4-5-1 MB FW-Version e n
4-5-2 MB FW-Revision e n
4-5-3 MB HW-Revision e n
1. Bold is Factory setting.
Parameter
Display
text
Value
1
description
Min./Max.
Read
Write
Help text
3-2-1-1 PIN e n Enter access level and personal identification
number
Access Level User Level
Service Level
Factory Level
e e Access Level
PIN acceptance 0
9999
e e PIN acceptance message
Login Login ok
Login failed
eeLogin
3-4-1-4-8-1 Threshold 1 ON 0
50
199.9
e s Water level at which the relays output becomes
""high""
3-4-1-4-8-2 Threshold 1 OFF 0
50
199.9
e s Water level at which the relays output becomes
""low""
3-4-1-4-8-3 Threshold 2 ON 0
40
199.9
e s Water level at which the relays output becomes
""high""
3-4-1-4-8-4 Threshold 2 OFF 0
40
199.9
e s Water level at which the relays output becomes
""low""
3-4-1-4-9-1 Level 1 open 0
70
99.9
e s Level in the receiver tank at which the supply
valve is opened
Parameter
Display
text
Value
1
description
Min./Max.
Read
Write
Help text
