42 Quick reference guide | Atlan SW 2.0n

Annex

10 Annex

The quick reference guide does not replace the instructions for use. Any use of the

medical device requires full understanding and strict observation of the instructions for use.

10.1 Symbols

Additional information about the symbols is available on the following web page:

www.draeger.com/md-symbols

Symbol Explanation

Group Views...

Group Trends/Data...

Group Alarms...

Procedures... group

Group System setup...

Group Start.../Standby...

Device on/Standby

Main switch on

Main switch off

Acoustic alarm signal is temporarily suppressed.

Battery completely charged

Battery empty

Central supply connected and pressure within specified range

Central supply not connected or pressure not within specified

range

Gas cylinder full

Gas cylinder empty or gas cylinder valve turned off

Gas cylinder pressure sensor not connected

Symbol for programmed Auto On
