Right-hand side view
1 Bracket for mounting unit in vehicles and for hanging
unit from wall rails and horizontal tubes up to 38 mm
diameter
2 Connector for external power supply (power supply
unit or on-board supply with converter)
3 Connector for O2, 2.7 to 6.0 bar
4 Connectors for flow measuring hoses
5 Inspiration connector, 22 mm ISO conical connector
6 Acoustic horn
7 Venting and ventilation – must not be obstructed!
8 Feet, may also be used to secure the carrying strap
What's what
Right-hand side view
42
8
1 2 3 4
5
6
7
MT 592-97
