ypical pneumatic operation time
at a minute volume of 10 L/min
11 L O2 cylinder Approx. 200 minutes without mixing (No Air Mix)
Approx. 400 minutes with mixing (Air Mix)
2,5 L O2 cylinder Approx. 45 minutes without mixing (No Air Mix)
Approx. 90 minutes with mixing (Air Mix)
Input voltage for Oxylog 2000 12 V ±1 V DC
Connection for
external power supply
12 V / 24 V / 28 V DC with DC/DC converter
Fuse F 1L 250V IEC 127 or
(behind the cover of the battery T 1L 250V IEC 127
compartment)
Current consumption for high-speed
charging of the NiCd battery pack
Ventilator OFF 300 mA (for 8 hours, then switches
automatically to trickle charging)
Ventilator ON 530 mA
Current for trickle charging 30 mA
Permissible ambient temperature
during charging 0 to 35 °C
Electrical operation time
with internal NiCd battery pack Max. 6 hours at 5 to 50 °C
Max. 3 hours at temperatures below 5 °C
Alkaline manganese batteries Max. 4 hours at 5 to 50 °C
Max. 2 hours at temperatures below 5 °C
with typical settings
Protection class Type BF m (body floating)
Type of protection IP 54 (splash-proof)
Protection class of
power supply unit II in accordance with EN 60601-1
Operating noise
Sound pressure level 48 dB(A) at a distance of 1 m
Dimensions
(W x H x D) mm 215 x 123 x 208 (without handle)
Weight 4.3 kg
O2 cylinder, 2.5 L, full 4.2 kg
O2 cylinder, 2.0 L, full 3.5 kg
Pressure reducer Alduk 1 0.9 kg
NiCd battery pack 0.15 kg
DC/DC converter
Operating environment To be used only according to installation class 0, EN 61000-4-5
Electrical safety All voltages are in the SELV range, EN 60601-1
Input voltage 10.5 V DC to 30.0 V DC
Output voltage 12.5 V DC (+0.5 V / –1.0 V)
Technical Data
46
