Dräger Pac 6500 - Troubleshooting; Error code

10
Troubleshootingen
6 Troubleshooting
An error message is displayed in the event of instrument faults. The number that appears below the message is used for service
functions. If the fault remains after turning the device on and off several times, contact the service of Dräger.
Error code Cause Remedy
101 Life span of the gas detector expired. Use a new Pac gas detector.
102 The user's service life counter has elapsed. Reset the service life counter with the Dräger
CC-Vision Basic PC software.
103 Gas detector faulty. Contact the service of Dräger.
104 Program code checksum error. Contact the service of Dräger.
105 Bump test interval expired. Carry out bump test, see see Section 4.2.3 on
Page 6.
106 Calibration interval expired. Carry out a span calibration.
107 Software error Contact the service of Dräger.
109 General error. For example, menu functions cannot
be carried out.
Check the configuration, view the error code (e.g. on
the information display or with the Dräger CC-Vision
Basic PC software)
111 Alarm element test failed: Alarm lamp. Repeat the alarm element test with X-dock.
112 Alarm element test failed: Alarm horn. Repeat the alarm element test with X-dock.
113 Alarm element test failed: Vibration motor. Repeat the alarm element test with X-dock.
114 Parameter check failed. Correct the parameters and repeat the test with
X-dock.
115 Gas detector deactivated by X-dock. Activate the gas detector with X-dock.
116 Wrong software version. Update the software.
117 User parameters implausible. Check and adjust the configuration of the user
parameters.
131 Gas detector faulty. Contact the service of Dräger.
132 Parameter checksum error. Carry out a sensor inauguration using the Dräger
CC-Vision Basic PC software.
133 Wrong software version for the options board Update the software.
134 Hardware error. Contact the service of Dräger.
201 No valid zero adjustment of DrägerSensor XXS
measuring channel 1.
Carry out a fresh air calibration, see Section 5.2 on
Page 8.
202 No valid span calibration of DrägerSensor XXS
measuring channel 1.
Carry out a span calibration, see Section 5.2 on
Page 8.
203 The measured value of DrägerSensor XXS
measuring channel 1 is in the negative range.
Carry out a fresh air calibration, see Section 5.2 on
Page 8.
204 DrägerSensor XXS measuring channel 1 is faulty or
not connected.
Check DrägerSensor XXS measuring channel 1, see
Section 7.4 on Page 13.
205 Error during the bump test of DrägerSensor XXS
measuring channel 1.
Repeat the bump test and calibrate or replace
DrägerSensor XXS measuring channel 1 if
necessary, see Section 7.4 on Page 13.
206 Faulty filter test. Repeat the filter test with X-dock.
207 Faulty rise time test. Repeat the rise test with X-dock.
208 User parameters of the sensor implausible. Check and adjust the configuration of the sensor
parameters.
212 Calibration interval of DrägerSensor XXS measuring
channel 1 expired.
Carry out a calibration, see Section 5 on Page 8.
225 Compensation channel error on DrägerSensor XXS
measuring channel 1.
Carry out a calibration, see Section 5 on Page 8.
