Internal: Spare parts list for technician
S u b j e c t t o c h a n g e w i t h o u t n
Spare Part List Spare Part ListEdition date
Dräger FPS 7000 RP/TR 23.07.2009 1412.952
Page: 3R56326, R56671, R56672, R56990, R57675, R57676
Image: 1R57677, R57678, R56670, R56673
POSITION DESIGNATION PART- ORDER PACK.
QTY.CODENUMMER
____________________________________________________________________________________________________________________________________________________________________________________________________
Kit:
R56990Draeger FPS 7000 RP-
R56410Mask Body EPDM-S, FPS 70001a
R56487Mask Body EPDM-M, FPS 70001b
R56402Mask Body EPDM-L, FPS 70001c
R56299Mask Body SI-S, FPS 70001d
R56488Mask Body SI-M, FPS 70001e
R56302Mask Body SI-L, FPS 70001f
R56226Upper visor frame FPS 70002
R56288Visor PCas3
R56227Lower visor frame, FPS 70004
101390020Screw M4 x 35 (Torx)5
20R56548Square nut M46
10R56340Clamp, FPS 70007
R56290Connector piece RP-T, cpl.8a
R56705Connector piece RP, cpl.8b
R56478Connector piece RP-T- TR, cpl.8c
R56985Connector piece RP-TR, cpl.8d
R56708Cover RP9a
R56709Cover RP-TR9b
10R57634Screw ISO 14583-M3X8-A210
R56236Turning knob11
201330233Disc A 3.2 DIN 125-A212
R56685Inner mask-1 RP13a
R56686Inner mask-2 RP13b
R56687Inner mask-3 RP13c
10R54664Button - bl.14
R54721Head strap M/L CR black15a
