Dräger PSS BG 4 plus

PSS BG4 / PSS BG4 plus [1114.231]
Spare parts list
Back plate assembly
T = purchase by authorised Service station only; X = subject to export approval
SL00184 0/09 Prod/Prod A | Prices per 25.10.2011 08:10:32 | Pub-ID 1114.231 | printed: 14.11.2011
DrägerSafety AG & Co KGaA | Subject to change | www.draeger.com
Service
Only
Item Number
Description
Order
Number
Product
group
Packing
quantity
Packing
unit
End of repair
-
CARRYING FRAME, COMPL. BG 4
R34150
591
1
ST
1
CARRYING SHELL BG4
R34151
591
1
ST
2
BUEGEL,VOLLST.
T
R34265
591
1
ST
3
BLIND RIVET CAP
R34052
591
1
ST
4
BNIET DIN 7337 A4X8-A2-A2
1390066
ST
5
HALTEBLECH
R33704
591
1
ST
6
MOUNTING BRACKET,ICE COOLER
T
R33748
591
1
ST
7
SCREW
1341227
591
10
ST
8
spring clip CO2-cartridge
R34593
591
1
ST
9
spring clip cooler
R34594
591
1
ST
10
SCREW
1341227
591
10
ST
11
WASHER,LOCKING,OXYCREW,DIN125
1327542
599
50
ST
12
DRAIN VALVE HOLDER,BG-4
R33747
591
1
ST
13
screw simil. DWN 562, 4x10
1390013
591
20
ST
14
CYLINDER HOLDER COMPLETE,BG-4
R33740
591
1
ST
14
CYLINDER RETAINER,BG-4
R33472
591
1
ST
15
BUFFER (RUBBER FOOT)
6800478
591
20
ST
16
BELT COMP,BG4
R33827
591
1
ST
17
SCREW
1341227
591
10
ST
18
WASHER B 4,3 DIN 9021-A4
1331914
19
SCHRAUBE DWN 562-4X12-F-A2-H
1343432
20
WASHER B 4,3 DIN 9021-A4
1331914
21
HOLDER BG-4
R33514
591
1
ST
22
RIVET, DIN7337A3x6-A4A4, BG-4(MUL50)
1341863
591
50
ST
23
B-RIVET A3X10 DIN 7337-A2
1390015
591
ST
24
WASHER B3,2 DIN 9021-A4
1335359
499
8
ST
25
SCREW
1341227
591
10
ST
26
WASHER B 4,3 DIN 9021-A4
1331914
27
HALTER, VOLLST.
R33317
28
HINGE,BG-4
R33148
591
1
ST
29-31
upgrade kit strengh.plate hinge
R34642
591
1
ST
29
Reinforcement plate closing hinge
R34579
30
Sleeve Nut
R34603
31
RAIS.COUNTERS.SCR.AM4X8 DIN964
1334816
599
5
ST
32-34
Spare set f. edge protector
R34527
591
1
ST
35
KIT ANTIVIBRATION DIVICE
R34236
591
1
ST
36
HOLDER
R34182
591
5
ST
37
Disc A 3.2 DIN 125-A2
1330233
599
20
ST
