Draetger BG4 Iso Training 3/12
PSS BG4 – Low Pressure Leak Isolation Step 1
CO2 SCRUBBER
COOLER
PRESSURE
REDUCER
with BYPASS
BREATHING BAG
OXYGEN
MINIMUM
VALVE
DRAIN
VALVE
RELIEF
VALVE
MP
RELIEF
VALVE
CONNECTOR PIECE
SENTINEL
M
E
D
P
R
E
S
S
U
R
E
SWITCH BOX
WITH FILTER
PRESSURE
TRANSDUCER
C
O
N
S
T
A
N
T
D
O
S
A
G
E
This will test the Inhalation and
Exhalation Hoses, Connector
Piece, CO2 Scrubber and Relief
Valve Assembly
T
x
O
mbar
CONNECTOR PLUG
FROM KIT
POSITIVE PRESSURE APPLIED
x
T
Draeger Training 11/16 rev 1
To Next Page
