Dräger X-act 7000 Technical Manual

Technical Manual | X-act
®
7000 53
Troubleshooting | en
Pneumat-
ics - error
524333
Self-test of the pneumatic system
when starting the X-act 7000 or
before a measurement was not suc-
cessful; the pump was not able to
achieve the normal mass flow on
time due to a blockage in the gas
path;
make sure that the gas outlet is
not sealed (e.g. by fingers, con-
tamination)
Pneumat-
ics - error
524334
The check to ensure that the Micro-
Tube to be measured is intact
before measurement was not suc-
cessful; the tip of the MicroTube
was damaged before measurement
Start new measurement
Pneumat-
ics - error
524335
The MicroTubes-specific mass flow
could not be achieved on time at the
start of the measurement due to a
blockage in the gas path; the tip of
the MicroTube on the outlet side
was not broken
Make sure that the gas inlet or
outlet is not sealed (e.g. by fin-
gers, contamination); when
using a pre-tube (e.g. ppb
Booster Basic), make sure that
all tips have been broken
Pneumat-
ics - error
524339
Deviation of the mass flow drawn in
by the pump too large over the
entire measurement duration
Make sure that the gas inlet or
outlet is not sealed (e.g. by fin-
gers, contamination); when
using a pre-tube (e.g. ppb
Booster Basic), make sure that
all tips have been broken
Mechanics
- error
524330
Mechanical integration of the Micro-
Tubes into the gas path was not
successful; the outlet side of the
MicroTube could not be contacted
by the gas needle
Start a new measurement; check
the MicroTubes housing for
excessive deformation and care-
fully bend it in the opposite direc-
tion if necessary
Mechanics
- error
524331
Mechanical integration of the Micro-
Tubes into the gas path was not
successful; the inlet side of the
MicroTube could not be contacted
by the gas needle
Start a new measurement; check
the MicroTubes housing for
excessive deformation and care-
fully bend it in the opposite direc-
tion if necessary
Mechanics
- error
524350
MicroTubes could not be removed Try to remove the MicroTubes
once again; if necessary, care-
fully open the door in front
Mechanics
- error
1048577
After measurement, the MicroTubes
could not be disconnected from the
gas path; transport to the next,
unused MicroTube is not possible
Turn the X-act 7000 off and back
on
Mechanics
- error
1048578
After measurement, the MicroTubes
could not be disconnected from the
gas path and/or the MicroTubes
cannot be transported
Make sure that the wells/doors
for MicroTubes are not blocked;
re-start the device and carry out
the process once again
Optics -
error
2097175
Competing optical parameters
occurred (lighting duration and
image capture frequency); incorrect
optical parameters read out on the
RFID tag of the MicroTubes
Do not use the MicroTubes any
further; insert new MicroTubes
for further measurements
Error Cause Remedy
