8 SECTION 2 | DESIGN OF THE DEVICE
SECTION 2 | DESIGN OF THE DEVICE
1. Probe ended with 2 measuring electrodes.
2. Graphic LCD display with LED backlighting.
3. Membrane keyboard.
4. Housing made of high-quality ABS.
5. Mini USB socket with rubber cover.
6. Compartment for four 1.5 V AA LR6 type batteries.
7. Battery compartment cover.
EXTERNAL DESIGN
4
3
6
2
5
7
1
