18
HDPQ IP Setup Program
A proprietary Dranetz setup utility program (HDPQIPSetup.exe) is
designed to scan the local network to find and detect HDPQ DataNode
units. This allows to you to discover HDPQ DataNodes on your network
when you do not know the instrument’s IP address. The IP Setup
program may be downloaded from the Dranetz website.
The utility program “HDPQIPSetup.exe” is particularly useful when the
network is configured for DHCP and the IP address cannot be known
until the network DHCP server assigns the IP after initial connection to
the network. In this case, the only way to discover the IP address is
through the use of the HDPQIPSetup tool.
System PC Requirements
Operating System
Category 5e Cable
Internet Browser
Windows
®
10, Windows
®
8 Professional
Standard RJ45 connector, cross-over cable
(Not Included)
Internet Explorer
®
11.x, Edge, Firefox, etc.
Follow these steps to use the HDPQIPSetup utility to locate the HDPQ
DataNode on your network.
NOTE: You may need Administrator privileges on your computer to run
the program since it is an executable (.exe) file.
Step Action
1 Copy the HDPQIPSetup.exe program to your Windows
®
computer.
NOTE: The HDPQIPSetup utility program only runs on
Windows
®
operating systems.
2 Connect the HDPQ DataNode to your computer directly with
a cross-over cable via the Ethernet port on the rear panel of
the instrument or connect to the same local area network
(LAN) of your computer via a router or hub.
3
Double click on the HDPQIPSetup executable file to run the
program.
Result
: The following screen opens.
