Section 7 - Wiring Diagrams: Motor with Internal Low-Voltage Controller
Motor with Internal Low-Voltage Controller: Switch-to-Motor
(Dry Contacts or Data Cable connection)
CAUTION: Although both Dry Contact and Data Cable connections are shown, only one connection type per motor should be used.
Please Note:
• This Splitter/Jack is located inside the motor-end endcap of screen. To access, remove access panel from endcap.
• Data Cables to switches or to additional motors can be plugged into any of the three open jacks.
Single Low-Voltage Control
Internal Screen Wiring
White (Neutral)
Black
Green (Ground)
Multiple Low-Voltage Controls
White (Neutral)
Black
Green (Ground)
Wall Switch,
RF or IR
Receiver,
or integrated
control system.
Wall Switches,
RF or IR
Receivers,
or integrated
control systems.
Data
Cable
Data
Cables
110-120V
Plug
110-120V
Plug
Multiple Station Control
White (Neutral)
Green/Yellow (Ground)
Internal Screen Wiring
Black
Dashed wiring
by electrician.
To 110-120V Line
Wall Switch,
RF or IR
Receiver,
or integrated
control system.
RJ-9
connector
Data Cables
Single Station Control
White (Neutral)
Green/Yellow (Ground)
Black
Internal Screen Wiring
Dashed wiring
by electrician.
Wall Switch,
RF or IR
Receiver,
or integrated
control system.
RJ-9
connector
Data Cable
To 110-120V Line
110-120V MOTOR AND QUIET MOTOR
(Internal Low-Voltage Controller for ILT motor)
Plug & Play 110-120V Motor
(Motor with internal low-voltage controller)
110-120V Motor
(Motor with internal low-voltage controller - ILT)
U
p
D
o
w
n
C
o
m
m
o
n
+
5V
DC
U
p
D
o
w
n
C
o
m
m
o
n
+
5V
DC
Data Cables to
switches or
additional motors
ILT Data Cable Connection
OR
MOTOR
DATA CABLE
Please Note: This Splitter/Jack is located
inside the junction box of your screen.
ILT Dry Contacts Connection
Please Note: 5V DC must be connected
to set limits using the wall switch.
to MOTOR
Back of
wall switch.
page 7 of 8
