Draper Targa - Product Dimensions

Section 8 - Dimensions
2 
(59mm)
5 
(149mm)
5 
(133mm)
 (6mm)
dia. hole
for mounting

(22mm)
electrical
connection
hole
 (6mm)
dia. holes
for suspending
with "S" Hooks
3 
(89mm)
VIEWING SURFACE
Fabric width + 7"
(178mm)
page 8 of 8
Targa
