D-1000B Heater Operations & Maintenance
Remove Plug From “P” Port
for Test Elbow Connection
Adjustment Screw Plug
ClockwisetoIncrease
Counter- Clockwise to Decrease
Figure 6-2 - Pressure Gauge Tester
TEST PROCEDURES 6-4 DHS SYSTEMS LLC
No rights are conveyed except as indicated in the legend on the inside front cover of this document.
