D-1000B Heater Operations & Maintenance
ILLUSTRATED PARTS BREAKDOWN 8-6 DHS SYSTEMS LLC
No rights are conveyed except as indicated in the legend on the inside front cover of this document.
8.6 Parts List for Exploded View of D-1000B Heater
Table 8-6 – Parts List
ITEM DHS PN DHS PART DESCRIPTION Qty.
1 1003778 Outlet Duct 1
2 1003779 Stack, Exhaust 1
3 1003780 Support, Combustion Chamber 1
4 1003781 Chamber, Combustion 1
5 1003782 Shield, Upper Heat 1
6 1008415 Shield, Lower Heat, Rev B 1
7 1003785 Cover, Access 1
8 1003786 Knob, Thumb Screw M5x15mm 3
9 1003787 Bushing 4
10 1003788 Motor 200W 1
11 1003789 Condenser 20 µF 1
12 1008416 Plate, Motor Assembly, Rev B 1
13 1003784 Inlet Duct 1
14 1003791 Shutter, Fresh Air 1
15 1003792 Fan 1
16 1003793 Nut, U-Style, Clip-On 8
17 1003794 Grill, Inlet Duct 1
18 1008417 Hose, Braided, 10"L, 1/4" female end 1
19 1003796 Fitting, Nipple Hex, 1/4" NPT 4
20 1003797 Bracket, Fuel Filter 1
21 1003798 Filter, Fuel (Pre-heated) 1
22 1003799 Hose, Braided, 17"L, 1/4" female end 2
23 1003800 Fitting, Nipple Hex, 1/4"M - M12 x 1.75mm 2
24 1003801 Tube, Fuel, 6"L 1
25 1003802 Tank, Fuel 10.8 Gal 1
To Next Page
