D-1000B Heater Operations & Maintenance
ILLUSTRATED PARTS BREAKDOWN 8-7 DHS SYSTEMS LLC
No rights are conveyed except as indicated in the legend on the inside front cover of this document.
Parts List for Exploded View of D-1000B Heater Continued:
Table 8-6 – Parts List (Cont)
ITEM DHS PN DHS PART DESCRIPTION Qty.
26 1003803 Cap, Fuel w/level indicator 1
27 1008418 Plug, Drain M16 x 1.5 1
28 1008419 O-ring Ø16mm x 2,62mm 1
29 1008420 Assembly, Panel Control, Rev B 1
30 1008421 Base, Rev B 1
31 1003808 Tube, Silicone Ø5x900mm 2
32 1008422 Fitting, Connector Straight, 1/8" NPT 1
34 1003811 Holder, Power Cord 1
35 1003812 Nut, Ring for Power Cord 1
36 1003813 Grommet, Rubber Ø35mm 1
40 1008423 Head, Combustion 1
41 1008424 Panel, Control, Rev B 1
42 1003819 Bracket for pressure switch 1
43 1008425 Switch, Pressure 1
44 1003821 Holder, Fuse 1
45 1003822 Fuse (6x30)10A 1
46 1003823 Terminal block 1
47 1003824 Terminal block 1
49 1003826 Transformer ASTRODYNE 1
53 1008426 Assembly, Ignition Control 1
