D-1000B Heater Operations & Maintenance
ILLUSTRATED PARTS BREAKDOWN 8-8 DHS SYSTEMS LLC
No rights are conveyed except as indicated in the legend on the inside front cover of this document.
Parts List for Exploded View of D-1000B Heater Continued:
Table 8-6 – Parts List (Cont)
ITEM DHS PN DHS PART DESCRIPTION Qty.
54 1003831 Light, Power Indicating 1
55 1003832 Cord, Power 1
56 1003833 Cap, w/lanyard 1
57 1003834 Plug, Thermostat (remote) 1
58 1003835 Switch, Power, 3-Position 1
59 1008427 Nozzle 0.55GPH 80°B 1
60 1003837 Holder, Nozzle 1
61 1008428 Flange, Burner, 80mm 1
62 1003839 Nut M14 1
63 1003840 Electrode 2
64 1008429 Cable, Ignition 2
65 1003842 Tube, Micro Fuel 1
66 1008430 Detector, Flame, FC13 1
70 1003847 Pump, Fuel BFP01 1
71 1003848 Coil, Solenoid, BFP11-21 1
71A Call DHS (Specialty) Nut, Cap 1
71B Call DHS Washer, Wave (for Specialty Nut Cap) 1
72 1003849 Valve, Solenoid 1
73 1003850 Nipple, Hex 1
74 1003851 Coupler, Shaft 1
75 1003852 Kit, O'-Ring, Fuel Filter 1
76 1003853 Filter, Fuel Cartridge 1
77 1008431 Cable, Heater, Wire Harness 1
