D-1000B Heater Operations & Maintenance
ILLUSTRATED PARTS BREAKDOWN 8-9 DHS SYSTEMS LLC
No rights are conveyed except as indicated in the legend on the inside front cover of this document.
Parts List for Exploded View of D-1000B Heater Continued:
Table 8-6 – Parts List (Cont)
ITEM DHS PN DHS PART DESCRIPTION Qty.
78 T270040
Screw, Hex Hd w/Washer, Tapping #10 x ½”L, 18-
8 SS
18
79 1004133 Screw, Cap Flange Hex Hd, M5 x 14mm 8
80 1004134 Washer, Spring 5mm, Zinc Plated 2
81 1004135 Screw, Mach Phil Pan Hd, M5 x 20mm 2
83 1004138 Screw, Self-Tap Phil Pan Hd, M4 x 9mm 6
85 1004140 Screw, Tapping Phil Pan Hd, #8 x 3/8” 9
86 1004141 Washer, Tooth Lock, 5mm Zinc Plated 2
87 1004142 Screw, Tapping Phil Pan Hd, #4 x ½”L 1
88 1008432 Screw, Tapping Phil Pan Hd, #8 x ½”L 2
92 1004147 Screw, Set Socket Standard M8 x 8mm 1
93 1008433 Holder, Flame Detector 1
94 1008434 Board, Terminal 1
95 1008435 Bracket, Safety Overheat Switch 1
96 1008436 Switch, Safety Overheat 1
97 1008437 Washer, 23mm ID x 29.5mm OD x 2mm 2
98 1008438 Protection, Reset Button 1
99 1008439 Bracket, Pressure Switch 1
100 1008440 Screw, Tap Phil Pan Head, #6 x 3/8” 2
101 1008441 Screw, Self-tap Pan Head, M4 x 8 x 13mm 3
102 1008442 Screw, Self-tap Pan Head, M4 x 8mm 3
103 T260024
Ground Wire, 16 AWG, 30”L (Burner Flange to Ctrl
Panel)
1
To Next Page
