Vigor130 Series User’s Guide
275
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
a
a
n
n
l
l
b
b
This command allows you to Enable/Disable for each WAN to join auto load balance
member.
wan lb [wan1/wan2] on
wan lb [wan1/wan2] off
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
wan1/wan2
It means to specify which WAN will be applied with load
balance.
on
It means to make WAN1/WAN2 as the member of load
balance.
off
It means to cancel WAN1/WAN2 as the member of load
balance.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wan lb status
WAN1: on
WAN2: on
WAN3: on
WAN4: on
WAN5: on
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
a
a
n
n
m
m
v
v
l
l
a
a
n
n
This command allows you to configure multi-VLAN for WAN and LAN. It supports pure
bridge mode (modem mode) between Ethernet WAN and LAN port 2~4.
wan mvlan [pvc_no/status/save/enable/disable] [on/off/clear/tag tag_no] [service type/vlan
priority] [px ... ]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
pvc_no
It means index number of PVC. There are 8 PVC (0,
Channel-1, to 7, Channel-8) allowed to be configured.
However, only 2 to 7 are available for configuration.
status
It means to display the whole Bridge status.
save
It means to save the configuration into flash of Vigor router.
enable/disable
It means to enable/disable the Multi-VLAN function.
on/off
It means to turn on/off bridge mode for the specific channel.
clear
It means to turn off/clear the port.
tag tag_no
It means to tag a number for the VLAN.
-1: No need to add tag number.
1-4095: Available setting numbers used as tagged number.
