Vigor130 Series User’s Guide
34
value is set by telnet command.
MTU
It means Max Transmit Unit for packet.
RIP Protocol
Routing Information Protocol is abbreviated as RIP(RFC1058)
specifying how modems exchange routing tables information.
Click Enable RIP for activating this function.
Bridge Mode
If you choose Bridged IP as the protocol, you can check this
box to invoke the function. The modem will work as a bridge
modem.
WAN IP Network
Settings
This group allows you to obtain an IP address automatically
and allows you type in IP address manually.
Obtain an IP address automatically – Click this button to
obtain the IP address automatically.
Modem Name – Type in the modem name provided by ISP.
Domain Name – Type in the domain name that you have
assigned.
DHCP Client
Identifier for some ISP
This feature is offered for certain ISP with special request.
Enable – Check this box to enable the function of DHCP client
identifier for some ISP.
Username – Type a username used for such function.
Password – Type a password used for such function.
Specify an IP address
Click this radio button to specify some data.
WAN IP Alias - If you have multiple public IP addresses and
would like to utilize them on the WAN interface, please use
WAN IP Alias. You can set up to 8 public IP addresses other
than the current one you are using. Notice that this setting is
available for WAN1 only. Type the additional WAN IP
address and check the Enable box. Then click OK to exit the
dialog.
