Draytek VigorAP 903 Quick Start Guide

Panel Explanation
LED Status Explanation
ACT Off The VigorAP is powered off
Blinking The VigorAP is ready and operating normally
USB On USB device is connected and ready for use
Blinking Data is being transmitted over USB
2.4G On 2.4GHz Access Point is active
Off 2.4GHz Access Point is turned off
Blinking Data is being transmitted on the AP’s 2.4GHz
wireless interface
5G On 5GHz Access Point is active
Off 5GHz Access Point is turned off
Blinking Data is being transmitted on the AP’s 5GHz
wireless interface
LAN A1 - A4 On Ethernet LAN (RJ45) is connected
Off Ethernet LAN is disconnected
Blinking Data is transmitting (sending/receiving)
LAN B On Ethernet LAN (RJ45) is connected
Off Ethernet LAN is disconnected
Blinking Data is transmitting (sending/receiving)

Draytek VigorAP 903 Specifications

General

Brand	Draytek
Model	VigorAP 903
Category	Wireless Access Point
Language	English
