Draytek VigorAP 903 Quick Start Guide

Installation
This section includes guidance on initial hardware connection of the VigorAP and
how to wall-mount the VigorAP.
1. Connect VigorAP 903 to your router, or a switch on your network through a
LAN-A port of the access point by Ethernet cable.
Note You can also connect the VigorAP 903 to a Vigor router via
wireless connection.
For detailed information, refer to the VigorAP 903 User Guide
2. Connect a computer to another LAN port on the VigorAP.
Make sure the subnet IP address of the PC is the same as VigorAP 903
management IP, e.g., 192.168.1.X.
3. Connect the A/C power adapter to the wall socket, and connect it to the PWR
connector of the access point.
4. Power on VigorAP 903.
5. Check all LEDs on the front panel. ACT LED should blink, LAN LEDs will
also be on if the access point is correctly connected to the router or network
switch.

Draytek VigorAP 903 Specifications

General

Brand	Draytek
Model	VigorAP 903
Category	Wireless Access Point
Language	English
