22 23
EN EN
Routine Maintenance
24h
Edge Sensor
AI Visual Sensor
LED Fill Lights
Line Laser Sensors
Laser Distance Sensor (LDS)
Bumper
Charging Contacts
Carpet Sensor
Cli Sensors
Filter
1. Remove the filter and tap its basket gently.
Note:
Do not attempt to clean the filter with a brush, a finger or sharp
objects to prevent damage.
2. Rinse the dust box and filter with water and dry them completely
before reinstalling.
Note:
·
Rinse the dust box and filter with clean water only. Do not use any
detergent.
·
Use the dust box and filter only when they are completely dry.
Robot Sensors and Charging Contacts
Wipe sensors and charging contacts of the robot by using a soft and dry
cloth, as shown in the below figure:
Note: A wet cloth can damage sensitive elements within the robot and
the base station. Please use a dry cloth for cleaning.
Routine Maintenance
Side Brush & Mop Pad Holder
Remove and clean the side brush and mop pad holder.
Omnidirectional Wheel
Note:
·
Use a tool such as a small screwdriver to separate the axle and tire of
the omnidirectional wheel. Do not use excessive force.
·
Rinse the omnidirectional wheel under the running water and put it
back after drying it completely.
Dust Box
1. Open the robot's cover and press the clip to remove the dust box.
2. Open the dust box cover and empty the dust box as shown in the diagram.
